Appendix A – Proposed Site Plan

Site plan showing ground floor footprint (Phase 1) and upper-storey projections, indicating areas of setback non-compliance and planned public realm interface.

5.1 BYLAW NO. 2058 "City of Langford Phased Development Agreement (798 Goldstream Ave, 2747, 2753, 2761 Peatt Rd, 2734, 2738, 2742, 2746 Claude Rd), Bylaw No. 2058, 2022"

Key facts

  • Shows ground floor encroachment of 1.18 m at Peatt Rd (noted in staff report)
  • Displays upper-storey projections and their relation to lot lines (Goldstream Ave, Peatt Rd, Claude Rd)

Appendix A – Proposed Site Plan

20220815 Council Meeting

Properties

  • 798 Goldstream Ave
  • 2747-2761 Peatt Rd
  • 2734-2746 Claude Rd
Proposed site plan for 798 Goldstream Ave, 2747-2761 Peatt Rd and 2734-2746 Claude Rd
Proposed site plan for 798 Goldstream Ave, 2747-2761 Peatt Rd and 2734-2746 Claude Rd
