SITE PLAN

Site plan for a proposed residential building on Massie Dr, showing the building layout, outdoor amenity area, landscaping, access, and parking.

12.2.3 Bylaw No. 2236 – Application to Rezone 709, 711, 715, 719, and 721 Massie Drive

Key facts

Massie Dr
Outdoor amenity area: 582 m²
Surface parking: 18 regular, 3 small, and 1 accessible stall; 22 stalls total
Bike room: 116 bikes

Site Plan

Site plan showing the building, patios, landscaping, outdoor amenity area, driveway and surface parking.

Site and building labels

MASSIE DR
SIDEWALK
PATIO (repeated along the north side of the building)
AMENITY AREA
LOBBY — MAIN FLOOR FFE 75.90
UNIT A — Studio (repeated)
UNIT B — 2 bedroom
CORRIDOR
CLOSET
BEDROOM 1
BEDROOM 2
STAIR 1
STAIR 2
ELEVATOR
MAIL ROOM
ELECTRICAL / MECHANICAL ROOM
STORAGE
BIKE ROOM — 116 BIKES
WASTE ROOM
OUTDOOR AMENITY — 582 m²
DRIVEWAY — 3% SLOPE
RAMP DOWN TO PARKING — 12% SLOPE
SURFACE PARKING
- 18 REGULAR
- 3 ACCESSIBLE
- TOTAL: 21 PARKING STALLS
LINE OF PARKING WALL BELOW
LINE OF BUILDING ABOVE

Parking dimensions

Parking-stall dimension diagrams, including an accessible stall.

3.65 m × 5.50 m
2.60 m × 5.50 m
2.60 m × 4.50 m

Site coverage

14094.73 SF (1309.44 m²)
AVERAGE GRADE = 75.31

Drawing notes

Additional fine-print dimensions, spot elevations, and plan annotations are present but are too small to read reliably.

Page 1
