Appendix A - 887 Klahanie Drive (Z21-0010) - Site Figures / Plans

Original PDF

Appendix to the 887 Klahanie Drive staff report containing site figures and original/new open space proposal diagrams.

3b PUBLIC HEARING — BYLAW NO. 1982 "Langford Zoning Bylaw, Amendment No. 626, (887 Klahanie Dr), Bylaw No. 1982, 2021"

Key facts

  • Includes figures comparing original open space proposal and the new proposal
  • Supports staff analysis regarding retained open space (25% retained; 5% cash-in-lieu)
  • Referenced in staff report conditions for replanting and biologist reports

Appendix A

Site plan showing a small residential subdivision with an internal road, ten numbered lots (1–10), and green areas labeled as common property greenspace
Site plan showing a small residential subdivision with an internal road, ten numbered lots (1–10), and green areas labeled as common property greenspace

Visible textual elements on the page (transcribed as seen)

  • "COMMON PROPERTY GREENSPACE"
  • "COMMON PROPERTY GREENSPACE" (appears twice on the plan)
  • "KLAHANIE DRIVE" (label on the adjoining road)
  • Lot numbers: "1", "2", "3", "4", "5", "6", "7", "8", "9", "10" (each shown on individual lots)
  • "LOT 21"
  • "LOT 3"
  • "LOT 9"
  • Several "PLAN" labels adjacent to lot numbers (partially legible)
  • Various small area labels adjacent to lots (not fully legible in image)
