BUILDING B FLOOR PLANS

Building B — Level 1

Scale: 3/32" = 1'-0"

Grid references: 1, 2, 3, 4, 5; A, B, C, D, E, F, G

Dimensions:

7.5 m / 24' - 7 1/2"
7.4 m / 24' - 4" (repeated)
0.9 m / 3' - 0"
9.5 m / 31' - 1 1/4"
0.5 m / 1' - 6"

Plan labels:

M. BEDROOM
WASH RM
ENTRANCE TO UPPER UNIT
KITCHEN
BEDROOM
DINNING
LIVING
STORAGE
LOWER UNIT
BACKYARD
BRIDGE TO BACKYARD ABOVE

Building B — Level 2

Scale: 3/32" = 1'-0"

Grid references: 1, 2, 3, 4, 5; A, B, C, D, E, F, G

Dimensions:

7.5 m / 24' - 7 1/2"
7.4 m / 24' - 4" (repeated)
0.9 m / 3' - 0"
9.5 m / 31' - 1 1/4"
0.5 m / 1' - 6"

Room labels and dimensions:

ENSUITE — 7'-8"X7'-7"
M. BDRM — 12'-9"X13'-1"
BATH — 10'-2"X6'-0"
W/D
BDRM 1 — 9'-10"X10'-2"
BDRM 2 — 11'-6"X11'-0"
W.I.C.

Building B — Level 3

Scale: 3/32" = 1'-0"

Grid references: 1, 2, 3, 4, 5; A, B, C, D, E, F, G

Dimensions:

7.5 m / 24' - 7 1/2"
7.4 m / 24' - 4" (repeated)
0.5 m / 1' - 6"
9.5 m / 31' - 1 1/4"
0.9 m / 3' - 0"

Plan labels:

BDROOM 1
BATHROOM
DINING
LIVING ROOM
KITCHEN
BRIDGE TO BACKYARD
Upper unit
Backyard
BALCONY

Additional dimensions:

10' - 0"
9' - 8"
11' - 6"
10' - 0"
11' - 2"
9' - 8"

Building B — Roof

Scale: 3/32" = 1'-0"

Grid references: 1, 2, 3, 4, 5; A, B, C, D, E, F, G

Dimensions:

7.5 m / 24' - 7 1/2"
7.4 m / 24' - 4" (repeated)
0.9 m / 3' - 0"
3.1 m / 10' - 0 3/4"
6.4 m / 21' - 0 1/2"
0.5 m / 1' - 6"

Roof slopes: 5:12; 12:12

Exterior Materials and Finishes

FIBER CEMENT HORIZONTAL SIDING - (ARCTIC WHITE) WITH LIGHT TRIM SLIM-LINE TRIM SYSTEM - (ANODIZED WHITE).
FIBER CEMENT LAP SIDING - NIGHT GREY
FIBER CEMENT VERTICAL SIDING - (ARCTIC WHITE) WITH LIGHT TRIM SLIM-LINE TRIM SYSTEM - (ANODIZED WHITE).
WINDOWS & BALCONY AL. DOOR FRAMES - (ANODIZED BLACK)
SMART TRIM FIBER CEMENT - MATCH WITH WINDOW FRAMES
THERMAL INSULATED ENTRY DOOR WITH FROSTED LIGHTS- (BLACK)
GARAGE DOOR WITH FROSTED TRANSOM - (PRE-FIN-BLACK)
ASPHALT SHINGLES - (CHARCOAL)
BALCONY RAILING - (ANODIZED BLACK PICKET AL.)
FASCIA - (WHITE ALUMINUM)

Drawing and Project Information

Drawing title: BUILDING B FLOOR PLANS
Project name: 2124 Longspur Dr, Langford, BC
Drawing number: A2.12A
DP No.: DP24-0040
Scale: As indicated
Date: 2026-07-07
Project number: 8/4/2026 2:24:53 PM
Drawn by: BK
Checked by: MC
Revision: 1 — 20260320 — DP AMENDMENT
Architect: MATTHEW CHENG ARCHITECT INC
Address: UNIT 202 - 670 EVANS AVENUE, VANCOUVER, BC V6A 2K9
T: 604.731.3012
M: 604.649.0669
E: MATTHEW@MCAI.CA

Drawing note: THIS DRAWING MUST NOT BE SCALED. THE GENERAL CONTRACTOR SHALL VERIFY ALL DIMENSIONS AND LEVELS PRIOR TO COMMENCEMENT OF WORK. ALL ERRORS AND OMISSIONS SHALL BE REPORTED IMMEDIATELY TO THE ARCHITECT. COPYRIGHT RESERVED. THIS PLAN AND DESIGN ARE AND AT ALL TIMES REMAIN THE EXCLUSIVE PROPERTY OF MATTHEW CHENG ARCHITECT INC. AND MAY NOT BE USED OR REPRODUCED WITHOUT PRIOR WRITTEN CONSENT.
