SCHEDULE A
Schedule A contains architectural floor plans for the development, including the second, third, and fourth floors. The plans identify unit layouts and areas, including studio and two-bedroom units.
Key facts
- Page 9 introduces Schedule A
- Pages 10–12 show second-, third-, and fourth-floor plans
SCHEDULE A
Page 9
[See following pages]
Drawing information
Project: 2797 SCAFE RD.
Project address: CITY OF LANGFORD, BC
Project No.: 24132
Street: SCAFE ROAD
Architect: Nick Bray Architecture Ltd.
Address: 2531 Ontario Street, Vancouver, BC, V5T 2X7
Website: www.nickbray.ca
Email: info@nickbray.ca
Phone: +1 604 900 8238
Status: NOT FOR CONSTRUCTION
Architects Seal
Copyright Notice: All rights reserved. All ideas, designs, drawings and reproductions either in print or electronic format, are the property of Nick Bray Architecture Ltd., and are an instrument of service that may not be used, forwarded to others, transmitted, downloaded or reproduced either in print or electronic format, without the express written permission of the copyright owner.
Written dimensions shall have precedence over scaled dimensions. Contractors shall verify and be responsible for all dimensions and conditions on the job; shall request clarification of errors, discrepancies, or doubtful information contained in contract drawings and documents. Failure to obtain such clarification renders the Contractor responsible for any resulting improper work and the cost of rectification.
Revision history
| REV | DATE | DESCRIPTION |
|---|---|---|
| 9 | 2-Jul-26 | DP Amendment revisions |
| 8 | 28-Apr-26 | Issued for DP Amendment |
| 7 | 13-May-25 | Issued for DP |
| 6 | 25-Mar-25 | Issued to consultants for DP |
| 5 | 12-Feb-25 | Issued to consultants |
| 4 | 24-Dec-24 | DP Issued to client |
| 3 | 16-Dec-24 | Issued for Tender |
| 2 | 17-May-24 | Revisions for Rezoning |
| 1 | 24-4-5 | Issued for Rezoning |
Page 10 — A104, Second Floor Plan
Scale: AS NOTED
Plan scale: 1/8" = 1'-0"
Plan labels: 1 BED; 1 BED+DEN; 2 BED; STUDIO; DECK; BALCONY; JULIET BALCONY; SETBACK; ELEVATOR; STAIR #1; STAIR #2; PLANTER; PARAPET; ROOF BELOW; MECH.; ELEC.; DN; UP; ATTAINABLE UNIT.
Unit and area labels: 658 SF.; 572 SF.; 617 SF.; 590 SF.; 565 SF.; 617 SF.; 805 SF.; 830 SF.; 640 SF.; 950 SF.; STUDIO 387 SF.; STUDIO 491 SF.; STUDIO 553 SF.
Balcony and outdoor area labels: 70 SF.; 58 SF.; 60 SF.; 164 SF.; 225 SF.; 153 SF.; 159 SF.; 65 SF.; 66 SF.; 60 SF.; 58 SF.; 70 SF.
Dimensions and plan annotations:
10'-6" [3.2m]; 8'-2" [2.49m]; 29'-11 1/2" [9.13m]; 6'-3" [1.9m]; 32'-0 1/2" [9.76m]; 76'-4 1/2" [23.29m]; 40'-6" [12.34m]; 17'-2" [5.23m]; 83'-0" [25.29m]; 10'-4" [3.15m]; 13'-1 1/2" [4m]; 4'-0 1/2" [1.23m]; 8'-11 1/2" [2.74m]; 18'-3"; 18'-0" [5.49m]; 21'-8 1/2" [6.61m]; 21'-8 1/2" [6.62m]; 21'-7" [6.58m]; 9'-10" [3m]; 6'-4 1/2"; 17'-3"; 6'-6 1/2" [1.99m]; 4'-7 1/2"; 10'-3" [3.13m]; 13'-1 1/2" [4m]; 21'-7" [6.57m]; 21'-8 1/2" [6.62m]; 21'-8 1/2" [6.62m]; 263.88'; 4'-5"; 20'-11 1/2" [6.39m]; 25'-1 1/2" [7.66m]; 3'-7 1/2" [1.11m]; 5'-4 1/2" [1.64m]; 3'-3" [0.99m]; 10'-7 1/2" [3.24m]; 11 1/2" [0.29m]; 3'-6"; 9'-0" [2.74m]; 12'-7" [3.83m]; 12'-4" [3.75m]; 9'-5" [2.86m]; 12'-3 1/2" [3.75m]; 9'-2" [2.79m]; 18'-3" [5.56m]; 34'-6" [10.52m]; 6'-0" [1.83m]; 8'-2" [2.49m]; 25'-1" [7.65m]; 3'-9" [1.14m]; 6'-3" [1.9m]; 7'-2 1/2" [2.2m]; 1'-1 1/2" [0.34m]; 37'-10" [11.53m]; 23'-11" [7.29m]; 9'-3 1/2" [2.83m]; 4'-1" [1.25m]; 21'-0 1/2" [6.42m]; 9'-9" [2.97m]; 11'-2 1/2" [3.42m]; 10'-7 1/2" [3.24m]; 9'-4 1/2" [2.86m]; 9'-5" [2.86m]; 12'-4" [3.75m]; 9'-5" [2.87m]; 12'-1 1/2" [3.7m]; 1'-5" [0.43m]; 4'-11 1/2" [1.52m]; 25'-0" [7.62m]; 4'-9" [1.44m]; 1'-5" [0.44m]; 6'-3 1/2" [1.92m].
Stairs: DN 25R; UP 18R; DN 19R; UP 18R.
Drawing references: 1 A301; 1 A302; 1 A303; 1 A304.
Grid/plan references: 1, 1, 2, 2, 5, 5, 6, 6, C, E, A, A, H, H, 3, 3, 4, 4, AA, D, AB, G, G, F, F, AC, AD, B.
Page 11 — A105, Third Floor Plan
Scale: AS NOTED
Plan scale: 1/8" = 1'-0"
Plan labels: 1 BED; 1 BED+DEN; 2 BED; STUDIO; BALCONY; JULIET BALCONY; SETBACK; ELEVATOR; STAIR #1; STAIR #2; MECH.; ELEC.; DN; UP; ATTAINABLE UNIT; W4A; W-01.
Unit and area labels: 658 SF.; 572 SF.; 617 SF.; 590 SF.; 617 SF.; 805 SF.; 830 SF.; 640 SF.; 565 SF.; 950 SF.; STUDIO 387 SF.; STUDIO 491 SF.; STUDIO 553 SF.
Balcony and outdoor area labels: 70 SF.; 58 SF.; 60 SF.; 65 SF.; 66 SF.; 64 SF.; 64 SF.; 57 SF.; 65 SF.
Dimensions and plan annotations:
8'-2" [2.49m]; 10'-6" [3.2m]; 40'-6" [12.34m]; 17'-2" [5.23m]; 83'-0" [25.29m]; 10'-4" [3.15m]; 13'-1 1/2" [4m]; 4'-0 1/2" [1.23m]; 8'-11 1/2" [2.74m]; 18'-3"; 21'-8 1/2" [6.61m]; 21'-8 1/2" [6.62m]; 21'-7" [6.58m]; 9'-10" [3m]; 6'-4 1/2"; 17'-3"; 4'-7 1/2"; 13'-1 1/2" [4m]; 21'-7" [6.57m]; 21'-8 1/2" [6.62m]; 21'-8 1/2" [6.62m]; 20'-11 1/2" [6.39m]; 25'-1 1/2" [7.66m]; 3'-7 1/2" [1.11m]; 29'-11 1/2" [9.13m]; 6'-3" [1.9m]; 32'-0 1/2" [9.76m]; 3'-3" [0.99m]; 11 1/2" [0.29m]; 5'-7 1/2"; 5'-7"; 4'-10 1/2"; 6'-6 1/2"; 10'-3" [3.13m]; 10'-7 1/2" [3.24m]; 9'-0" [2.74m]; 12'-7" [3.83m]; 12'-4" [3.75m]; 9'-5" [2.86m]; 12'-3 1/2" [3.75m]; 9'-2" [2.79m]; 18'-3" [5.56m]; 34'-6" [10.52m]; 6'-0" [1.83m]; 8'-2" [2.49m]; 25'-1" [7.65m]; 3'-9" [1.14m]; 6'-3" [1.9m]; 7'-2 1/2" [2.2m]; 1'-1 1/2" [0.34m]; 37'-10" [11.53m]; 23'-11" [7.29m]; 9'-3 1/2" [2.83m]; 4'-1" [1.25m]; 21'-0 1/2" [6.42m]; 9'-9" [2.97m]; 11'-2 1/2" [3.42m]; 10'-7 1/2" [3.24m]; 9'-4 1/2" [2.86m]; 9'-5" [2.86m]; 12'-4" [3.75m]; 9'-5" [2.87m]; 12'-1 1/2" [3.7m]; 1'-5" [0.43m]; 4'-11 1/2" [1.52m]; 25'-0" [7.62m]; 4'-9" [1.44m]; 10'-6" [3.2m]; 8'-2" [2.49m]; 29'-11 1/2" [9.13m]; 6'-3" [1.9m]; 32'-0 1/2" [9.76m]; 76'-4 1/2" [23.29m]; 5'-4 1/2" [1.64m]; 1'-5" [0.44m]; 18'-0" [5.49m]; 6'-3 1/2" [1.92m]; 273.88'.
Stairs: DN 18R; UP 18R; DN 18R; UP 18R.
Drawing references: 1 A301; 1 A302; 1 A303; 1 A304.
Grid/plan references: 1, 1, 2, 2, 5, 5, 6, 6, C, E, A, A, H, H, 3, 3, 4, 4, AA, D, AB, G, G, F, F, AC, AD, B.
Page 12 — A106, Fourth Floor Plan
Scale: AS NOTED
Plan scale: 1/8" = 1'-0"
Plan labels: 1 BED; 1 BED+DEN; 2 BED; STUDIO; BALCONY; JULIET BALCONY; SETBACK; ELEVATOR; STAIR #1; STAIR #2; MECH.; ELEC.; DN; UP; ATTAINABLE UNIT; W4A.
Unit and area labels: 658 SF.; 572 SF.; 617 SF.; 590 SF.; 617 SF.; 805 SF.; 830 SF.; 640 SF.; 565 SF.; 950 SF.; STUDIO 387 SF.; STUDIO 491 SF.; STUDIO 553 SF.
Balcony and outdoor area labels: 70 SF.; 58 SF.; 60 SF.; 65 SF.; 66 SF.; 64 SF.; 64 SF.; 57 SF.; 65 SF.
Dimensions and plan annotations:
8'-2" [2.49m]; 10'-6" [3.2m]; 40'-6" [12.34m]; 17'-2" [5.23m]; 83'-0" [25.29m]; 10'-4" [3.15m]; 13'-1 1/2" [4m]; 4'-0 1/2" [1.23m]; 8'-11 1/2" [2.74m]; 18'-3"; 21'-8 1/2" [6.61m]; 21'-8 1/2" [6.62m]; 21'-7" [6.58m]; 9'-10" [3m]; 6'-4 1/2"; 17'-3"; 4'-7 1/2"; 13'-1 1/2" [4m]; 21'-7" [6.57m]; 21'-8 1/2" [6.62m]; 21'-8 1/2" [6.62m]; 20'-11 1/2" [6.39m]; 25'-1 1/2" [7.66m]; 3'-7 1/2" [1.11m]; 29'-11 1/2" [9.13m]; 6'-3" [1.9m]; 32'-0 1/2" [9.76m]; 3'-3" [0.99m]; 11 1/2" [0.29m]; 5'-7 1/2"; 5'-7"; 4'-10 1/2"; 6'-6 1/2"; 10'-3" [3.13m]; 10'-7 1/2" [3.24m]; 9'-0" [2.74m]; 12'-7" [3.83m]; 12'-4" [3.75m]; 9'-5" [2.86m]; 12'-3 1/2" [3.75m]; 9'-2" [2.79m]; 18'-3" [5.56m]; 34'-6" [10.52m]; 6'-0" [1.83m]; 8'-2" [2.49m]; 25'-1" [7.65m]; 3'-9" [1.14m]; 6'-3" [1.9m]; 7'-2 1/2" [2.2m]; 1'-1 1/2" [0.34m]; 37'-10" [11.53m]; 23'-11" [7.29m]; 9'-3 1/2" [2.83m]; 4'-1" [1.25m]; 21'-0 1/2" [6.42m]; 9'-9" [2.97m]; 11'-2 1/2" [3.42m]; 10'-7 1/2" [3.24m]; 9'-4 1/2" [2.86m]; 9'-5" [2.86m]; 12'-4" [3.75m]; 9'-5" [2.87m]; 12'-1 1/2" [3.7m]; 1'-5" [0.43m]; 4'-11 1/2" [1.52m]; 25'-0" [7.62m]; 4'-9" [1.44m]; 10'-6" [3.2m]; 8'-2" [2.49m]; 29'-11 1/2" [9.13m]; 6'-3" [1.9m]; 32'-0 1/2" [9.76m]; 76'-4 1/2" [23.29m]; 5'-4 1/2" [1.64m]; 1'-5" [0.44m]; 18'-0" [5.49m]; 6'-3 1/2" [1.92m]; 283.88'.
Stairs: DN 18R; UP 18R; DN 18R; UP 18R.
Drawing references: 1 A301; 1 A302; 1 A303; 1 A304.
Grid/plan references: 1, 1, 2, 2, 5, 5, 6, 6, C, E, A, A, H, H, 3, 3, 4, 4, AA, D, AB, G, G, F, F, AC, AD, B.
