Appendix K

Building B Floor Plans

Project: 2124 Longspur Dr, Langford, BC
Drawing: A2.12A — BUILDING B FLOOR PLANS
DP No.: DP24-0040
Scale: As indicated
Architect: MATTHEW CHENG ARCHITECT INC
Project date: 2026-07-07
Drawn by: BK
Checked by: MC

Building B — Level 1

Drawing 1: BUILDING B_LEVEL 1 — 3/32" = 1'-0"

Plan labels: M. BEDROOM; WASH RM; ENTRANCE TO UPPER UNIT; KITCHEN; BEDROOM; DINNING; LIVING; STORAGE; LOWER UNIT; BACKYARD; BRIDGE TO BACKYARD ABOVE.

Building B Level 1 floor-plan drawing detail

Building B — Level 2

Drawing 2: BUILDING B_LEVEL 2 — 3/32" = 1'-0"

Room labels and dimensions:

Room	Dimension
ENSUITE	7'-8"X7'-7"
M. BDRM	12'-9"X13'-1"
BATH	10'-2"X6'-0"
BDRM 1	9'-10"X10'-2"
BDRM 2	11'-6"X11'-0"
W/D
W.I.C.

Building B — Level 3

Drawing 3: BUILDING B_LEVEL 3 — 3/32" = 1'-0"

Plan labels: BDROOM 1; BATHROOM; DINING; LIVING ROOM; KITCHEN; BRIDGE TO BACKYARD; BALCONY; Upper unit; Backya rd.

Dimensions shown: 10' - 0"; 9' - 8"; 11' - 6"; 10' - 0"; 11' - 2"; 9' - 8".

Building B — Roof

Drawing 4: BUILDING B_ROOF — 3/32" = 1'-0"

Roof pitches shown: 5:12; 12:12.

Plan dimensions and grid references

Grid references shown: 1, 2, 3, 4, 5; A, B, C, D, E, F, G.

Dimensions shown:

7.5 m / 24' - 7 1/2"
7.4 m / 24' - 4"
0.9 m / 3' - 0"
9.5 m / 31' - 1 1/4"
0.5 m / 1' - 6"
3.1 m / 10' - 0 3/4"
6.4 m / 21' - 0 1/2"

Exterior materials and finishes

FIBER CEMENT HORIZONTAL SIDING - (ARCTIC WHITE) WITH LIGHT TRIM SLIM-LINE TRIM SYSTEM - (ANODIZED WHITE).
FIBER CEMENT LAP SIDING - NIGHT GREY
FIBER CEMENT VERTICAL SIDING - (ARCTIC WHITE) WITH LIGHT TRIM SLIM-LINE TRIM SYSTEM - (ANODIZED WHITE).
WINDOWS & BALCONY AL. DOOR FRAMES - (ANODIZED BLACK)
SMART TRIM FIBER CEMENT - MATCH WITH WINDOW FRAMES
THERMAL INSULATED ENTRY DOOR WITH FROSTED LIGHTS- (BLACK)
GARAGE DOOR WITH FROSTED TRANSOM - (PRE-FIN-BLACK)
ASPHALT SHINGLES - (CHARCOAL)
BALCONY RAILING - (ANODIZED BLACK PICKET AL.)
FASCIA - (WHITE ALUMINUM)

Drawing notes and revision

UNIT 202 - 670 EVANS AVENUE
VANCOUVER, BC V6A 2K9
T: 604.731.3012
M: 604.649.0669
E: MATTHEW@MCAI.CA

THIS DRAWING MUST NOT BE SCALED. THE GENERAL CONTRACTOR SHALL VERIFY ALL DIMENSIONS AND LEVELS PRIOR TO COMMENCEMENT OF WORK. ALL ERRORS AND OMISSIONS SHALL BE REPORTED IMMEDIATELY TO THE ARCHITECT. COPYRIGHT RESERVED. THIS PLAN AND DESIGN ARE AND AT ALL TIMES REMAIN THE EXCLUSIVE PROPERTY OF MATTHEW CHENG ARCHITECT INC. AND MAY NOT BE USED OR REPRODUCED WITHOUT PRIOR WRITTEN CONSENT.
