Appendix: Proposed Site Plan & Landscape Plan (893 Klahanie Drive)

Appendix: Proposed Site Plan & Landscape Plan (893 Klahanie Drive)

Project Information

• Project Address: 893 Klahanie Drive, Langford, B.C.
• Prepared for: Dan Charboneau
• Project #: 8901
• Drawn By: MIS
• Date (Site Plan): Feb 28, 2025
• Scale (Site Plan): 1 : 200
• Contact (Designer address block): #105 - 859 ORONO AVENUE, LANGFORD, B.C. V9B 2T9; P. 250.382.7374; F. 250.382.7364
• Landscape Plan sheet: L1
• Landscape Plan Date: October 7, 2024
• Landscape Plan Status: REZONING ONLY — Not for Construction
• Client (Landscape): Dan Charboneau
• Landscape Plan Project: 893 KLAHANIE DR DEVELOPMENT
• Landscape Plan Dwg. No.: 0989
• Landscape Plan Scale: AS NOTED

Project Notes / Title Block (excerpt)

COPYRIGHT RESERVED. WRITTEN CONSENT IS REQUIRED FROM THE DESIGNER BEFORE ANY REPRODUCTION.

Proposed Rezoning

Proposed Green Space: 2429.78 M2

Field survey dated this 15th and 22nd day of April, 2024.

NOTE: Lot dimensions, offsets, and area shown may vary upon completion of a comprehensive legal survey. Geodetic elevations shown are based upon GNSS observations to geodetic control monuments 03H2522 (Elev.=81.767m) and 95H2056 (Elev.=61.571m). This plan is for building design & permit purposes only and is for the exclusive use of our client. This plan shall not be used to define property lines or property corners. Unregistered interests have not been included or considered. PID: 003-154-238 Lot dimensions shown are based upon field survey measurements and may vary from those registered.

Legend (symbols called out on plan)

• Denotes ground elevation
• Denotes utility pole
• Denotes catch basin
• Denotes water meter
• Denotes sewer manhole
• Denotes anchor
• Denotes BC Hydro
• UP (denotes upward direction on plan)
• WM (water meter)
• S (sewer)
• BCH (BC Hydro)

Site Data

Selected Site / Plan Callouts (verbatim excerpts where present)

• BLOCK 1 — UNIT A, UNIT B

• BLOCK 2 — UNIT A, UNIT B, UNIT C, UNIT D

• BLOCK 3 — UNIT A, UNIT B, UNIT C, UNIT D

• BLOCK 4 — UNIT A, UNIT B, UNIT C, UNIT D

• BLOCK 5 — UNIT B, UNIT C, UNIT D

• BLOCK 6 — UNIT A, UNIT B, UNIT C

• BLOCK 7 — UNIT A, UNIT B

• BLOCK 8 — UNIT A, UNIT B, UNIT C

• BLOCK 9 — UNIT A, UNIT B, UNIT C

• BLOCK 10 — UNIT A, UNIT B, UNIT C

• PATHWAY

• Visitor Parking (multiple locations labeled)

• Concrete Driveway, Gravel areas, Asphalt (callouts present)

• PROPOSED GREEN SPACE 2429.78 M2

• SKETCH PLAN OF LOT 21, SECTION 69, METCHOSIN DISTRICT, PLAN 23855.

• (Proposed Strata Plan EPS10099)

• Proposed Easement Area Plan EPP134715

• Proposed Strata Lot 1

• Proposed Strata Lot 11

• Proposed Common Property (noted)

Survey / Elevations (selected numeric excerpts)

• Numerous ground elevations and grade callouts appear across the plan (examples shown: 84.0, 86.1, 88.3, 90.9, 91.5, 90.7, ... up to values > 104, 100+, etc.)
• Top of Rock Wall / Bottom of Rock Wall / Top of Bank / Bottom of Bank callouts are present in multiple locations.
• Approximate Location of Septic Field and Septic Tank Lids noted.

Notes about Use

This plan is for building design & permit purposes only and is for the exclusive use of our client. This plan shall not be used to define property lines or property corners. Unregistered interests have not been included or considered.
